Boundary Survey Drafting Services

PROFESSIONAL BOUNDARY SURVEY DRAFTING

A boundary survey defines the legal limits of a property, and getting it wrong can delay a closing, trigger a dispute, or send a project back to the field. ArcusCAD converts deed research, recorded plats, and field monumentation into legally sound, defensible boundary drawings that are cross-checked against title reports and adjoining parcels before they ever reach your desk.

We understand that a boundary drawing is only as good as the research behind it, so our drafters take the time to trace deed history, review prior surveys, and reconcile any inconsistencies before a single line is plotted. The result is a drawing your firm can stand behind, whether it is used for a simple property line confirmation or as evidence in a formal boundary dispute.

Request Quote

WHAT WE DO:

Plot bearings, distances, and curve data directly from your field notes and point files
Run closure calculations and flag gaps, overlaps, or title discrepancies for surveyor review
Call out monuments found and set, easements, rights of way, and encroachments clearly on the drawing
Format legal descriptions and certification blocks ready for your surveyor's seal
Cross-reference adjoining deeds and recorded plats to catch conflicts before submission
Prepare exhibit-quality boundary maps for legal review, title work, or client presentations

Our Quality Drafting Process

Field Data Connection & Parsing

We parse total station raw coordinates files to accurately construct lines matching your description keys.

Deed & Title Overlay Checks

We trace historical records, easements exceptions, and setbacks on top of the boundary vectors to ensure no missing overlaps.

Deliverables & Formats

DWG / DXF Native Format: Clean layered files configured to your specific template styles.
High-Res PDF Prints: Title blocks formatted ready for stamping and archiving.

Boundary Survey Drafting
